Broken Conductor Protection in numrAL FDR22 Relay

Updated: Sep 09, 2026 | 6 min read

Technical Articles

Published: Mar 11, 2026 by Rajesh R Shirodkar

Technical Articles

Click on any topic to jump to that section

Introduction

A broken conductor or open circuit fault is one of the most difficult faults to detect in power systems. It often does not cause a significant increase in current, making it hard for standard overcurrent relays to sense.

The Challenge

Standard unbalance protection (ANSI 46) uses negative-sequence current (I2) to detect faults. However, at low load levels, the negative-sequence current produced by a broken conductor can be very small — sometimes even smaller than the normal unbalance present in the system. This makes it risky to set sensitive pickup values without causing false tripping.

The Smart Solution: I2/I1 Ratio

The numrAL FDR22 relay from Lauritz Knudsen uses Broken Conductor Protection based on the I2/I1 ratio (Negative-sequence current to Positive-sequence current).

This ratio remains relatively constant even when load changes, making it a much more reliable way to detect broken conductors or open circuits.

Key Features of FDR22 Broken Conductor Protection

Uses I2/I1 ratio for accurate detection
Pickup setting adjustable from 20% to 100%
Time delay setting from 0.01 sec to 100 sec
Works effectively on both single-point and multiple-earthed systems

Why It Matters

Broken conductor faults can lead to dangerous voltage unbalance, equipment damage, and safety risks. The advanced Broken Conductor Protection in the numrAL FDR22 relay helps detect such faults quickly and reliably, enhancing system safety and protection.

Conclusion

For reliable detection of broken conductors, the Lauritz Knudsen numrAL FDR22 feeder protection relay offers a smart and sensitive solution using the I2/I1 ratio.

Takeaway: Don’t rely only on standard unbalance protection — use dedicated Broken Conductor Protection for better safety.
