Front Image
6A SP 6KA TYPE C MCB
Cat Number
:
 BA10060C
The MCB is a vital protection device that is essential in every electrical installation to safeguard both your life and valuable property against Short-circuits and Overloads

Specifications

General
Short Description
6A SP 6KA TYPE C MCB
Conformity to Standard
IS/IEC 60898-1, EN/IEC 60898-1
Poles
1P
Electrical Characteristics
Operational Frequency (Hz)
50Hz / 60Hz
Rated breaking capacity
6kA
Rated impulse withstand voltage (Uimp)
4kV
Rated insulation voltage (Ui)
500VAC
Rated operational voltage (Ue)
240V/415V
Tripping Characteristic
C Curve
Environmental Conditions
IP Rating
IP20
Features
Mounting positions
Horizontal/Vertical/Flat
Suitable for isolation
Yes
Life
Electrical life-Operating Cycles
20,000
Mechanical life-Operating Cycles
1,00,000
Physical Dimensions
Height
87
Width
18
Depth
75
Weight
0.128
Termination
Termination capacity
35 mm2 (Rigid), 25 mm2 (Flexible)
Tightening Torque
4Nm
