Front Image
MCB 32A FP C-TYPE (ME)
Cat Number
:
 BA40325C
The MCB is a vital protection device. It is essential in every electrical installation to safeguard both your life and valuable property against short-circuit and overload.

Specifications

General
Short Description
MCB 32A FP C-TYPE (ME)
Conformity to Standard
IS/IEC 60898-1, EN/IEC 60898-1
Poles
4P
Frame
4 Module
Electrical Characteristics
Operational Frequency (Hz)
50Hz / 60Hz
Rated breaking capacity
6kA as per IS/IEC 60898-1
Rated impulse withstand voltage (Uimp)
4kV
Rated insulation voltage (Ui)
500VAC
Rated operational voltage (Ue)
415V
Tripping Characteristic
C Curve
Environmental Conditions
Ambient temperature
-25°C to +70°C
Degree of protection
IP20
IP Rating
IP20
Features
Mounting positions
Horizontal/ Vertical/ Flat
Suitable for isolation
Yes
Mounting positions
Horizontal/ Vertical/ Flat
Life
Electrical life-Operating Cycles
10,000
Mechanical life-Operating Cycles
1,00,000
Physical Dimensions
Height
87.3
Width
70
Depth
74.5
Weight
0.512
