xD4000 415V Drive 37.0kW(HD)/45.0kW(ND)

Cat Number

:

XD4000-88P0-4C2221

This Product is compatible with

Specifications

General

Short Description

xD4000 415V Drive 37.0kW(HD)/45.0kW(ND)

Conformity to Standard

IEC 61800-3,IEC 61800-5-1,IEC 60721-3,IEC 61000-3-12

Electrical Characteristics

Rated operational voltage (Ue)

380-480VAC

Rated kW

37.0kW(HD)/45.0kW(ND)

Environmental Conditions

Ambient temperature

-15 – +50 °C

IP Rating

IP21

Pollution Degree

II

Physical Dimensions

Height

673

Width

226

Depth

274

Weight

28.7
