BC401610

Specifications

General

Short Description

16A 4P RCCB (100mA SENSITIVITY)

Conformity to Standard

IS 12640-1, IEC 61008-1

Poles

Region

Made in India

Electrical Characteristics

Operational Frequency (Hz)

50 Hz

Rated Conditional SC Current

6kA

Rated Current

16A

Rated impulse withstand voltage (Uimp)

4kV

Rated insulation voltage (Ui)

500VAC

Rated Residual Making & Breaking capacit

1kA

Sensitivity

100mA

Environmental Conditions

Environment

RoHS & REACH

IP Rating

IP20

Operating temperature

-5°C to +55°C

Pollution Degree

Features

Load-line bias

Modules

Mounting positions

Horizontal/Vertical/Flat

Suitable for isolation

Yes

Features Fields

True Contact Indication, World-class Safety Standards- ISI, IEC & CE, Bi-connect Terminals, Line-load Reversibility, Large Terminal size- 50 sq. mm., Finger-proof terminals IP20, Combi head Screw, Ergonomically designed and manufactured with fire-retardan

Life

Electrical life-Operating Cycles

10,000

Physical Dimensions

Height

Width

Depth

Termination

Terminal capacity

50 mm2 (Rigid), 35 mm2 (Flexible)

Tightening Torque

4Nm
